400A Bus Bar 12V | Power Distribution Block Busbar with 8 x 3/8" (M10) Studs wtih Cover 400 Amp
4.3 (148 items)
Limited Time SaleUS$24.59 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 212197219 | Release Date | 2026/04/06 | List Price | US$16.40 | Model Number | 212197219 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- BusBar Material: Tin-Plated Copper,Base Material: Glass Fiber and Reinforced Nylon,glass fiber reinforced
- Voltage: 12V-48V DC ,400 Amps with M10 TERMINAL STUDS high current combiner box, , easy wiring configuration.
- Unique Design:Module box design, great for multiple battery wiring configurations
- Battery Power Distribution Block Bus Bar Box measured (L x W x H): 6.61"x 3.11"x 1.57" ( 168x79x40mm)
- Widely applicable to 12-48V Automotive RV Car Marine Truck Boat Battery Audio and other industrial equipment.
| Color | 400A M10-Red&Black |
|---|---|
| Gauge | 1 |
| Model | 1553RB |
| Voltage | 48 Volts |
| Brand Name | T Tocas |
| Unit Count | 1.0 Count |
| Item Weight | 572 Grams |
| Part Number | 1553RB |
| Manufacturer | T Tocas |
| Material Type | Tin-Plated Copper |
| Mounting Type | Screw Mount |
| Connector Type | Surface |
| Current Rating | 400 Amps |
| Number Of Poles | 8 |
| Centerline Length | 16.8 Centimeters |
| Specification Met | S.a.e. J1625, J1171, Ul1500 |
| Temperature Range | -32ºC to 82ºC Degrees Celsius |
| Number Of Contacts | 1 |
| Included Components | 1 set 400a Bus Bar Box with 8 x M10 Posts Terminals & Cover, Screws |
| Number of Positions | 8 |
| Warranty Description | Manufacture provide 6 months warranty upon order time |
| Item Dimensions W x H | 3.11"W x 1.57"H |
| Upper Temperature Rating | 100 Degrees Celsius |
