DGS Series Signaling and Duty Cycle 24 Hour Time Switch with 2 Channel, 24 VAC 50/60 Hz Input Supply, SPDT Output Contact

This NSi Industries DG280A digital time switch accepts 24 VAC input and its SPDT output contacts can activate a 20 amp load on each of its two channels. This timer includes 56 pairs of on/off set points, has a minimum cycle time of one minute, and is suitable for use where on/off operation is required at the same time each day. A rechargeable super capacitor provides seven days of backup power to maintain time and schedule settings. This timer can adjust for daylight saving time and leap year. The single-pole double-throw (SPDT) contacts are housed within a Noryl plastic alloy enclosure that meets NEMA-3R standards for water resistance and has a lockable hasp. The enclosure is suitable for both indoor and outdoor use and mounts to an external surface. This digital timer is Underwriter Laboratories (UL) Listed and Canadian Standards Association (CSA) certified for quality assurance and is suitable for controlling lighting, heaters, and equipment motors.SpecificationsSwitch typeDigital 24-hour timer with 56 unique set points each day. Skip-a-day operation. Two channel operation.Input power supply24 VAC, 50/60 Hz, 6 W power consumption, rechargeable super capacitor backupOutput contactsSPDT contacts, 20 amp load ratingOn/off controlOne-minute minimum on/off cycle, up to 56 cycles per 24 hoursEnclosureNEMA-3R Noryl plastic alloy enclosure with clear Lexan cover, indoor/outdoor use, external surface mountTerminal wire size range#12 to #18 AWG (American wire gauge)Operating temperature range-31 to +131 degrees F (-35 to +55 degrees C)Standards metUL Listed, CSA certifiedAutomatic switches are used to turn on or off electrical devices and are activated by time, light, and motion. Time activated switches (also known as timers) operate at preset time intervals during a daily or weekly period and can be either mechanical or electronic. Mechanical timers feature a dial with multiple pins to set the on/off time intervals. Electronic timers feature an LCD display and pushbuttons to set the time intervals. Light activated switches (also known as optical or photo) operate when ambient light levels reach preset values, generally measured in foot candles. Motion-activated switches (also known as motion sensors) operate when an electronic field of a preset range is interrupted. These switches can include energy saving logic that uses combinations of time, light, and motion to operate and can include one or more device outlets or circuit contacts. Automatic switches are used to control indoor lights, outdoor lights, appliances, and small equipment motors.NSi Industries manufactures electrical components and sensors, lighting products, and energy management products. The company, founded in 1975, is headquartered in Huntersville, NC.

• Automatic on/off control for operation at same time each day of two channels
• Digital 24-hour display with 56 on/off cycles each day, one-minute minimum cycle, manual override switch
• Automatic compensation for daylight saving time and leap year
• 24 VAC input voltage for low-voltage uses
• Noryl plastic alloy indoor/outdoor enclosure with locking hasp
